wholesale magnetic level gauge manufacturers for industrial

KAIDI magnetic level gauge manufacturers for industrial-1

Specifications：
Medium Density	≥ 0.5Kg / L
Medium pressure	≤ 5.0Mpa
Medium temperature	-40 ~ 130 °C / 120 °C
Measuring range	300-6000mm
Accuracy	± 8mm
Measuring tube material	PP/PVDF/UPVC
Float material	PP/PVDF/UPVC
Connection	Flange connection (Customizable)
Top Connection	Dome + race header (Customizable)
Limit switch	Customizable
Whether the remote	Customizable
Whether the explosion	Customizable

Measurement Principle

A change of level in the process tank corresponds to a similar change within the KDMLI chamber. In response to the level movement, the KDMLI float moves accordingly, actuating the flags or shuttle for visual indication.

Features

*Numerous chamber styles (or configurations) for each design. Custom designs available.

*Complete range of level switches and level transmitters, including Eclipse Guided Wave Radar

*Fabricated, non-magnetic chamber assembly produced in a wide range of metal and plastic materials

*ANSI and EN 1092 process connections available

*Precision manufactured float with internal magnets and magnetic flux ring

*Flag or shuttle type indicator with stainless steel scale to measure height, volume, or percentage of level

*Standard float stop springs at top and bottom of chamber

APPLICATIONS

*Exceptional code qualified welding

*Feed water heaters , Industrial boilers

*Oil/water separators

*Flash drums, Surge tanks

*Gas chillers

*Deaerators

*Blowdown flash tanks

*Hot wells

*Vacuum tower bottoms

*Alkylation units

*Boiler drums

*Propane vessels, Storage tanks

f******n

Kaidi Sensors magnetic level gauge has passed the following tests. They include statics testing, dynamics testing, the strength of materials testing, vibrations testing, reliability testing, and fatigue testing. The product is available in various kinds of sizes and styles

y******f

In the development of Kaidi Sensors magnetic level gauge, several disciplines were adopted. They are mechanical engineering, physical mechanics, hydraulic transmission and control, etc. The length of this product can be customized according to needs

u******u

Kaidi Sensors magnetic level gauge is of high quality. It is precision treated in manufacturing to eliminate any defects, including porosity, cracks, and roughness. Its smooth wall reduces the wear and tear on the skin

g******l

Kaidi Sensors magnetic level gauge is carefully manufactured. It will be processed by stamping, CNC machining, surface treatments such as coatings and paints. Its streamlined design can effectively reduce tissue damage of the patients

c******k

Fine workmanship has been adopted during the production of Kaidi Sensors magnetic level gauge. It is fabricated under mold shaping or compression molding to achieve robust and stiff mechanical structure. The product is not impervious to fade and yellowing

a******w

The product will never be out of shape. Its heavy-duty components and parts are perfectly designed to withstand extreme industrial conditions. The length of this product can be customized according to needs
