top radar level manufacturers for detecting

Company Advantages
1. radar level Selected high-quality raw materials, using first-class manufacturing technology and fine processing technology, exquisite workmanship, excellent workmanship, high quality, reliable and trustworthy quality.
2. This product allows people to do a wide of movements without any restrain feeling. It somewhat improves mobility. This product can be used in many different industries such as food & beverage, water, energy, pharmaceutical, etc
3. Advanced testing equipment and perfect quality assurance system ensure high quality products. This product has a high level of insulation
4. This product has high performance and good durability. This product is easy to install and use

PRODUCT OVERVIEW

KD-FMF series sensors are 120G FM radar type level measuring instruments with a measuring distance of up to 150 meters. The antenna is further optimized for processing and the new fast microprocessor allows for higher speed signal analysis and processing, making the meter available for measurement of high temperature and high pressure and other environmental solids.

THE PRODUCT PRINCIPLE

The general principle of frequency modulated continuous wave radar level meter is that the radar emits electromagnetic waves at the top of the tank, and the electromagnetic waves are received by the radar after hitting the medium and reflected. Because the speed of light C and FM slope K are known, so the frequency difference δ f is estimated, and the distance R of the material surface at the radar installation position can be obtained, and then the height of the material level is obtained by subtracting the spatial distance from the radar to the material surface (referred to as the empty height) from the known total height of the tank.

PROTECTION GRADE

This instrument fully meets the requirements of protection class IP66/67.

 Please make sure that the cable sealing head is waterproof. As shown

How to ensure that the installation meets the requirements of IP67:

Please make sure that the sealing head is not damaged.

Please ensure that the cable is not damaged.

Please ensure that the cable used meets the requirements

 of the electrical connection specification.

Before entering the electrical connection, bend the cable

 downwards to ensure that water does not flow into the housing, see ①

Please tighten the cable sealing head, see ②

Please plug the unused electrical connections with blind plugs, see ③

PRODUCT SPECIFICATION

Measuring medium: solid

Measuring range: 0.3m~150m

Process connection: flange ≥ DN80

Process temperature: -40～110℃

Process pressure: -0.1～0.3MPa

Accuracy: ±5mm

Protection level: IP67

Frequency range: 123GHz

Power supply: two-wire (DC24V) / four-wire (DC12V~24V) / four-wire / six-wire (AC220V)

Explosion-proof grade: Exia ⅡC T6 Ga / Exd IIC T6 Gb

Housing: Aluminum / Plastic / Stainless steel

Signal output: 2-wire 4.... .20mA / HART protocol / 4-wire / 6-wire 4.... .20mA /RS485 Modbus

APPEARANCE OF SIZE

TECHNICAL PARAMETERS

INSTRUMENT LINEARITY

INSTALLATION REQUIREMENTS

When installing the instrument, avoid installing it above the inlet, and try to avoid various objects that affect the signal, such as stirring paddles, etc.

● Under extremely complex working conditions, the instrument can work normally without any obstacle in the area of 20cm radius centered on the radar installation point.





Company Features
1. Guangdong Kaidi Energy Technology Co., Ltd. is an excellent radar level manufacturer.
2. Due to years of industrial history, our factory has very mature processing technic and advanced manufacturing facilities. This enables us to focus on improving product quality.
3. We strive to bring the following primary benefits to our business partners: the achievement of cost reduction goals and green initiative development.
