Kaidi Sensors temperature transmitter factory for work

Company Advantages
1. A wide range of tests is performed on Kaidi Sensors . These tests encompass all of the ANSI/BIFMA, CGSB, GSA, ASTM standards related to furniture testing as well as mechanical testing of furniture components. It is suitable for extreme pressure conditions
2. One of the reasons that why Kaidi Sensors is so popular in temperature transmitter industry is its strict quality assurance. This product features very low no-load losses
3. Guangdong Kaidi Energy Technology Co., Ltd. Not only insist on using high-quality and reasonably priced raw materials for manufacturingtemperature transmitter , but also strictly control every link of product production to ensure that all raw materials can be fully utilized, reduce the loss rate of raw materials, and promote the production of Guangdong Kaidi Energy Technology Co., Ltd. 10058] Compared with other products in the market, it has a more prominent price advantage.
4. The company strictly controls product quality and production costs, strives to reduce procurement costs in production, strengthens material management, reduces material consumption, establishes a complete quality management system in terms of product quality, and adopts strict quality inspection measures to ensure that [ 10368] are high-quality products with high cost performance.

Platinum resistance thermometers (PRTs) offer excellent accuracy over a wide temperature range (from –200 to +850 °C). Standard sensors are are available from many manufacturers with various accuracy specifications and numerous packaging options to suit most applications. Unlike thermocouples, it is not necessary to use special cables to connect to the sensor.

The principle of operation is to measure the resistance of a platinum element. The most common type (PT100) has a resistance of 100 ohms at 0 °C and 138.4 ohms at 100 °C. There are also PT1000 sensors that have a resistance of 1000 ohms at 0 °C.

The relationship between temperature and resistance is approximately linear over a small temperature range: for example, if you assume that it is linear over the 0 to 100 °C range, the error at 50 °C is 0.4 °C. For precision measurement, it is necessary to linearise the resistance to give an accurate temperature. The most recent definition of the relationship between resistance and temperature is International Temperature Standard 90 (ITS-90).

The linearization equation is:

Rt = R0 * (1 + A* t + B*t2 + C*(t-100)* t3)

Where:

Rt is the resistance at temperature t, R0 is the resistance at 0 °C, and
A= 3.9083 E–3
B = –5.775 E–7
C = –4.183 E–12 (below 0 °C), or
C = 0 (above 0 °C)

For a PT100 sensor, a 1 °C temperature change will cause a 0.384 ohm change in resistance, so even a small error in measurement of the resistance (for example, the resistance of the wires leading to the sensor) can cause a large error in the measurement of the temperature. For precision work, sensors have four wires- two to carry the sense current, and two to measure the voltage across the sensor element. It is also possible to obtain three-wire sensors, although these operate on the (not necessarily valid) assumption that the resistance of each of the three wires is the same.

Company Features
1. Our temperature transmitter are all made by eco-friendly and raw to make healthier for human body.
2. Sustainability is embedded in our operational practices. We have made great efforts in energy efficiency and pollution reduction. We also have embedded sustainability in culture.
