Kaidi KD Mica Water Level Gauge for monitoring the water level of steam boilers

这里可以自定义设置
Kaidi KD Mica Water Level Gauge for monitoring the water level of steam boilers

Kaidi KD Mica Water Level Gauge for monitoring the water level of steam boilers
  • Kaidi KD Mica Water Level Gauge for monitoring the water level of steam boilers
  • H2aaeb9f9918843e4a8757028b515f98d4.png
Kaidi KD Mica Water Level Gauge for monitoring the water level of steam boilers
B站不支持库存规格
Application:
monitoring the water level of steam boilers or other pressure vessels in power plants, petrochemical and industrial and mining enterprises
Process Connection:
Flangeless welding type
MOQ
1 SET
Payments:
TT, Paypal, Credit card, Western union
Shipping ways:
Express(DHL,Fedex,TNT,EMS,UPS)/Air/Sea
参数暂无数据
B站不支持优惠卷

Add success, do you want to check your shopping cart?

暂无分享
B站不支持产品保障
PRODUCT INTRODUCTION

The two-color mica water level gauge is a one-time direct-reading instrument for monitoring the water level of steam boilers or other pressure vessels in power plants, petrochemical and industrial and mining enterprises. It is the latest development based on various trans-missive two-color water level gauges at home and abroad. A new type of two-color water level gauge of, the water level gauge has the characteristics of high measurement accuracy, good observation effect, and long service life of window components.



The self-flushing two-color water level gauge is a functional design of the body on the basis of the traditional two-color water level gauge, adding a strong flushing function.



A condenser can be added to the top of the water level gauge body, the inside of the condenser is separated by a partition with a middle hole, and it is biased to the outside. The partition is to prevent the condensate from flowing to one end, and the deviation to the outside is because the outside temperature is low, and the formation of condensate is fast. The purpose is to prevent the condensate from flowing in the two rows of windows. When the saturated steam in the steam drum flows through the condenser, the heat dissipation function of the condenser is used to form a large amount of salt-free pure water. The dirt attached to the mica in the observation window is washed away. More importantly, the formed large amount of purified water flows back into the body cavity and continuously replaces with the saturated water in the body. Finally, the saturated water in the body cavity becomes pure water without salt and impurities, so that the window is free of scales. The color is high-definition and long-lasting, which improves the observation effect and prolongs the service life of the window assembly.


PRINCIPLE STRUCTURE

WORKING PRINCIPLE

The light emitted by the light source passes through the red and green filter lenses and is directed to the liquid cavity of the water level gauge body. In the vapor phase of the cavity, the red light is directed straight ahead, while the green light is absorbed obliquely to the wall. In the liquid phase part of the cavity, the green light is directed toward the front due to the refraction of the water level, while the red light is directed obliquely to the wall. Therefore, when viewed directly in front, the display shows red, green, and steam.

TECHNICAL PARAMETER
Monitoring methodDirect front visual or color monitor monitoring
Water level displayColor separation according to medium, steam red, water green
Installation center distance670mm or according to user requirements
Lighting source24V DC 60W Light Emitting Diode (LED)
Interface formWelding or flange connection
The visible range can also be specially manufactured according to user requirements


SELECTION TABLE
Modelillustrate
UBYSYafeng Mica Two-color Water Level Gauge
structure type1Single row2Double row
Process connectionSWFlangeless welding typeFFlange type
Connection specificationsOmitLiquid level monochrome15DN15
20DN2025DN25
32DN3240DN40
50DN5065DN65
80DN80100DN100
Installation directionLInstallation on the leftRInstallation on the right
Pressure rating (MPa)4PN405Class300
6.3PN6310PN 100
11CL600LB15CL900LB
16PN16025CL1500LB
42CL2500LB

RangeRange (mm)


DIMENSIONS

该产品后台详情无内容

Please Send Us your Application details

Measuring range , medium, Installation method (flange, thread), Pressure range, Remote transmitter, Level alarm switch

Our technical team will check your specifications and make a best solution for you.
