top magnetostrictive level sensor company for transportation

Specifications：
Medium Density	≥ 0.5Kg / L
Medium pressure	≤ 5.0Mpa
Medium temperature	-40 ~ 130 °C / 120 °C
Measuring range	300-6000mm
Accuracy	± 8mm
Measuring tube material	PP/PVDF/UPVC
Float material	PP/PVDF/UPVC
Connection	Flange connection (Customizable)
Top Connection	Dome + race header (Customizable)
Limit switch	Customizable
Whether the remote	Customizable
Whether the explosion	Customizable

Measurement Principle

A change of level in the process tank corresponds to a similar change within the KDMLI chamber. In response to the level movement, the KDMLI float moves accordingly, actuating the flags or shuttle for visual indication.

Features

*Numerous chamber styles (or configurations) for each design. Custom designs available.

*Complete range of level switches and level transmitters, including Eclipse Guided Wave Radar

*Fabricated, non-magnetic chamber assembly produced in a wide range of metal and plastic materials

*ANSI and EN 1092 process connections available

*Precision manufactured float with internal magnets and magnetic flux ring

*Flag or shuttle type indicator with stainless steel scale to measure height, volume, or percentage of level

*Standard float stop springs at top and bottom of chamber

APPLICATIONS

*Exceptional code qualified welding

*Feed water heaters , Industrial boilers

*Oil/water separators

*Flash drums, Surge tanks

*Gas chillers

*Deaerators

*Blowdown flash tanks

*Hot wells

*Vacuum tower bottoms

*Alkylation units

*Boiler drums

*Propane vessels, Storage tanks

j******o

In the design phase, many factors of Kaidi Sensors magnetostrictive level sensor have been taken into account. These factors include statics, dynamics, the strength of materials, resistance to vibrations, reliability, and anti-fatigue performance. APTEK produces connectors with precision, quality, and competitiveness

g******r

Kaidi Sensors magnetostrictive level sensor is a design integrating intelligence. Automatic control and automation detection technologies that are highly efficient are adopted into its design. APTEK produces connectors with precision, quality, and competitiveness

y******m

Various machining methods are adopted in the production of Kaidi Sensors magnetostrictive level sensor. They are mainly lathe work, drilling process, cutting process, abrasive machining, CNC machining, and hone machining. At APTEK, there are highly efficient production lines for cable cutting, soldering, crimping, etc

s******i

The quality process of Kaidi Sensors magnetostrictive level sensor begins with a full contract review of each order. Each component is reviewed for mechanical performance prior to production. Founded in 2009, APTEK is a professional manufacturer of industrial waterproof connectors

m******z

Kaidi Sensors magnetostrictive level sensor has been analyzed in many aspects, such as operational efficiency, safety, functionality, productivity, components performance, ease of operation and maintenance. At APTEK, certificates such as ROHS and UL are strong evidence of our capabilities

l******w

The product is reliable in operation. It can constantly perform its tasks while holding the highest level without any failure. APTEK supplies different custom services for different applications such as food & beverage business
