KAIDI wholesale magnetrol level transmitter manufacturers for work

Company Advantages
1. The quality and performance characteristics of KAIDI ultrasonic type level transmitter are ensured by random sampling. Manual testing such as frame color, lens color and surface quality is performed during this process. It is suitable for extreme pressure conditions
2. Guangdong Kaidi Energy Technology Co., Ltd. can also introduce the production methods of all types of magnetrol level transmitter for free. This product can repeat the same measurement many times
3. This product is safe to use. It uses the appropriate safety devices, including emergency stop buttons and protective covers. With a simple structure, it is perfectly good for demanding industrial applications

features: 　 Rod antennas made of PP or PTFE have a certain degree of corrosion resistance.

Should be used: 　 liquid measurement under simple process conditions.

Maximum range: 　30m

Measurement accuracy: 　±10mm

Process connection: 　G1½A

Antenna material: 　PP/PTFE

Process temperature: 　-40…120°C

Process pressure: 　-1.0…3bar

Frequency range: 　6GHz　　　　　　

Signal output: 　two-wire system/four-wire system 4…20mA/HART　　　　



Detailed introduction:

GDRD51

license

P Standard type (non-explosion-proof)

I Intrinsically safe type (Exia IIC T6)

C Intrinsically safe type + marine license (Exia IIC T6)

G Intrinsically safe type + flameproof type (Exd [ia]ia IIC T6)

Antenna type/material/process temperature

A Plastic rod/PP/-40～+120 ℃



B Plastic rod/PTFE/-40～+120 ℃



Container takeover length

A 50mm

B 100mm

C 150mm

D 200mm

E 250mm

F 300mm

X Special customization

Process connection/material

GP thread G1½A

NP thread 1½NPT

YP Special

Electronic components

B (4～20)mA/HART two-wire system

C (4～20)mA/(22.8～26.4)V DC/HART two-wire/four-wire system

D (198～242)V AC/HART four-wire system

Enclosure rating

A Aluminum/IP67

B Plastic/IP66

D Aluminum two-chamber/IP67

G Stainless steel 316L/IP67

Cable entry

M M20x1.5

N ½NPT

On-site display/programming

A belt

X without

Note: Intrinsically safe + marine license (Exia IIC T6) is limited to "A" or "B" electronic components and "G" type enclosure; intrinsically safe + flameproof type (Exd [ia]ia IIC T6) is limited to use "D" shell.

Company Features
1. We have imported a series of flexible and modern production facilities. They are perfectly suited to offering scalable manufacture, from one-off custom design products, right up to bulk production runs.
2. We work with ISO-certified suppliers who have the right working conditions, working times, and who conduct their work without undue risk or pressure.
