top float switch water level factory for industrial

Company Advantages
1. KAIDI float switch water level is manufactured through a series of processes to harmonize the needs of hygiene with the aesthetics of enduring simplicity and beauty. Its power ratings can be customized e based on requests
2. The product has become so integral to people's modern life. It brings many benefits to people, such as cutting electricity bills and conserving energy. It is suitable for extreme pressure conditions
3. This product has long service life, good performance, good quality and other competitive advantages. This product has the advantage of high accuracy

1.Product introduction

LF-20D side-mounted float level switch is characterized by easy use, simple structure, safe and reliable, long working life, small size, fast speed, sturdiness and durability, and the contact life can reach 1 million times. It is widely used in petrochemical industry, generator equipment, food industry, water treatment, electrician and other industries.

2.Working principle

When the floating ball floats up and down under the action of liquid buoyancy, the reed switch (or micro switch) in the junction box interacts with the arm end magnet to cause the reed switch (or micro switch) to act. At the same time, it outputs ON (ON) and OFF (OFF) signals for alarm notification or remote control.

3.Product characteristics

(1) It can be installed horizontally on the side wall of the tank or vertically on the top of the tank;

(2)The structure is simple, the performance is stable and reliable, and the installation is convenient;

(3)The control part is completely isolated from the measured liquid medium and can be used in high temperature and high pressure environments;

(4) Multiple materials and connection methods can meet the needs of different environments;

(5)Wide range of applications: food, medicine, chemical, electronics, shipbuilding, water treatment and other industries;

4.Specifications and Models

KAIDI top float switch water level factory for industrial-1

Thread standard type

（1） Junction box: aluminum/IP65

（2） Output contact: 5A/220VAC

（3） Contact form: SPDT (IC)

（4） Operating pressure: 15Bar

（5）Operating temperature: -20--120°C

（6） Wetted material: SUS304/316

（7） Applicable proportion: 0.65

Top-mounted standard type

（1） Junction box: aluminum/IP65

（2）Output contact: 5A/220VAC

（3） Contact form: SPDT (IC)

（4）Operating pressure: 30Bar

（5） Operating temperature: -20--120°C

（6） Wetted material: SUS304/316

（7）Applicable proportion: 0.55

5.Selection Guide

KAIDI top float switch water level factory for industrial-2

Company Features
1. Guangdong Kaidi Energy Technology Co., Ltd. has high-tech machines and skillful workers.
2. Our company recognizes increasingly serious environmental issues as a topmost priority. So we integrate circular thinking into product and process design to facilitate sustainable resources usage and foster profitable circular business.

i******f

The manufacturing of Kaidi Sensors float switch water level requires different high efficient testing tools. It will be checked for electric performance by virtue of a test pen, cable fault locator, electric screwdrivers, and thermistor detector.

e******c

Strict quality inspection on Kaidi Sensors float switch water level will be conducted. It is required to pass the quality standards such as RoHS, REACH, MSDS in the battery industry.

q******v

Kaidi Sensors float switch water level has passed the test for flammability. The testing principle is straightforward. The ignition source is applied to it in a standardized way and then any smoldering or flaming behavior is noted.

g******x

The electrical safety tests for Kaidi Sensors float switch water level have been professionally conducted. It is mainly tested for its continuity, voltage, and amperage.

d******d

The manufacturing of Kaidi Sensors float switch water level requires precision machining tools. The electric screwdrivers, test pen, and other full system assemblies offer increased speed, flexibility, and precision during product fabrication.

r******t

Its quality meets the requirements of high quality standards and is certified.
