KAIDI magnetic flow meter company for transportation

Company Advantages
1. KAIDI industrial flow meter is made by using good quality material and latest machine technology under the supervision of the team of the experts and professionals. This product can be used in many different industries such as food & beverage, water, energy, pharmaceutical, etc
2. This product looks beautiful and feels good, providing a consistent style and functionality. It adds to a room's design aesthetic. Due to its corrosive coatings, this product is highly rust-proof
3. Now the performance of this product is improved at every turn by powerful technologies. There is little variation between its measuring values

A magnetic flow meter (mag meter, electromagnetic flow meter) is a transducer that measures fluid flow by the voltage induced across the liquid by its flow through a magnetic field. A magnetic field is applied to the metering tube, which results in a potential difference proportional to the flow velocity perpendicular to the flux lines. The physical principle at work is electromagnetic induction. The magnetic flow meter requires a conducting fluid, for example, water that contains ions, and an electrical insulating pipe surface, for example, a rubber-lined steel tube.

If the magnetic field direction were constant, electrochemical and other effects at the electrodes would make the potential difference difficult to distinguish from the fluid flow induced potential difference. To mitigate this in modern magnetic flowmeters, the magnetic field is constantly reversed, cancelling out the electrochemical potential difference, which does not change direction with the magnetic field. This however prevents the use of permanent magnets for magnetic flowmeters.

Specifications

- Size: DN10~DN600 (PTFE) ; DN40~DN1200 (NBR)

- Standard pressure: PN1.0MPa~40MPa;

- Accuracy: ±0.5%~±1.0%;

- Supply power: 85 to 250VAC (45 to 63Hz), 16 to 36VDC;

- Signal output: Current Output: 4~20mA;

- Frequency Output: 0~5000Hz with photoelectric isolation;

- Pulse Output: 0.001~1.000m3/cp, 0.001~1.000 Ltr/cp, 0.001~1.000USG/cp,0.001~1.000 UKG/cp;

- Alarm Output: Upper Alarm-ALMH, Lower Alarm-ALML with photoelectric isolation;

- Communications: RS-232 without galvanic isolation, RS-485 with Galvanic isolation;

- Ambient temperature: -10~60;

- Relative humidity: ≤85%RH;

- Atmospheric pressure: 86KPa~106KPa;

- Applicable Fluid: electrically conducting liquid;

- Fluid temperature:-25~ +65 and -25~ +180;

- Electrical conductivity: 5us/cm.

Company Features
1. Guangdong Kaidi Energy Technology Co., Ltd. is an experienced and reliable manufacturer and supplier of magnetic flow meter and is highly prestigious in product design and manufacture.
2. Guangdong Kaidi Energy Technology Co., Ltd. has strong designing capability and advanced production technology for magnetic flowmeter production.
3. We cooperate with internationally trusted logistic service providers such as DHL, EMS, and UPS who ship our products to over 20 countries around the world. Get quote!
