best float level meter for business for transportation

Special 　　 sign: 　All PTFE antenna, strong corrosion resistance, no sanitary corners.

Should be used: 　 Suitable for highly corrosive environment and sanitary environment, simple process liquid measurement.

Maximum range: 　30m

Measurement accuracy: 　±10mm

Process connection: 　PTFE flange flange

Antenna material: 　PTFE

Process temperature: 　-40…150°C

Process pressure: 　-1.0…16bar

Frequency range: 　6GHz

Signal output: 　Two-wire system/four-wire system 4…20mA/HART

Detailed introduction:

GDRD52

Permit

P Standard type (non-explosion-proof)

I Intrinsically safe type (Exia IIC T6)

C Intrinsically safe type + marine license (Exia IIC T6)

G Intrinsically safe type + flameproof type (Exd [ia]ia IIC T6)

Antenna type/material/process temperature

B Plastic rod/PTFE/-40～+150℃

Container takeover length

A 50mm

B 100mm

C 150mm

D 200mm

E 250mm

F 300mm

X Special customization

Process connection

FC PTFE flange flange DN50 PN1.6 stainless steel 316L (GB/T9119-2000)

FD PTFE flange flange DN80 PN1.6 stainless steel 316L (GB/T9119-2000)

FE PTFE flange flange DN100 PN1.6 stainless steel 316L (GB/T9119-2000)

FK PTFE flange flange DN150 PN1.6 stainless steel 316L (GB/T9119-2000)

YP Special

Electronic components

B (4～20)mA/HART two-wire system

C (4～20)mA/(22.8～26.4)V DC/HART two-wire/four-wire system

D (198～242)V AC/HART four-wire system

Enclosure rating

A Aluminum/IP67

B Plastic/IP66

D Aluminum two-chamber/IP67

G Stainless steel 316L/IP67

Cable entry

M M20x1.5

N ½NPT

On-site display/programming

A belt

X without

Note: Intrinsically safe + marine license (Exia IIC T6) is limited to "A" or "B" electronic components and "G" type enclosure; intrinsically safe + flameproof type (Exd [ia]ia IIC T6) is limited to use "D" shell.

b******e

Removal of the edge, or flash, from a Kaidi Sensors float level meter can be accomplished in a number of ways including manual tear trimming, cryogenic processing, tumbling precision grinding. The sound of this product is loud enough for outside usage

d******o

Kaidi Sensors float level meter has achieved quality management system certification in accordance with both domestic and international standards in regards to porcelain manufacture. Its components guarantee its effective acoustic output

l******b

During the designing stage of Kaidi Sensors float level meter, sketches and CAD technique are used by the designers who strive to create a product with the function of foot orthopedic. Featuring high sonic accuracy, this product produces high-quality audio signals

s******l

Kaidi Sensors [拓展关键词 is superior in raw materials. Inferior materials are totally rejected into the factory, which ensures the luminous efficiency. It is designed with a short circuit protection system

i******q

In the manufacture of Kaidi Sensors float level meter, a range of techniques have been used, from CAD design, 3D imaging, model manufacturing, to final assembly. With CE certification, it produces no harmful radiation effect for users

u******d

Long service life absolutely manifests its superior performance. It is designed with a short circuit protection system
