BASIC INFO
Function:
BJZT-IV is a multi-point thermometer deisgned to meet the demand of temperature measurement for both custody transfer and inventory control applications. It is featured with integrating Water/Oil interface measurement. It can provide the temperature and water interface information to other instrument by Hart or Modbus communication, or it can work standalone.
Application:
Measure temperature elements and average temperature of liquid in the tank, featured with measuring water interface level.
FEATURES
Rapid response ensures its high accuracy in output;
♦ Precise structure, quality build and reliable protection ensure its long life span;
♦ Up to 16 points can be measured;
♦ It supports RS485 MODBUS, HART protocols;
♦ It can work in a harsh and corrosive environment.
SPECIFICATION
Item | Spec |
Power Supply | 24V/DC |
Work Current | 30mA |
Measure Points | 6 - 16 points |
Accuracy | ± 0.1℃ |
Communication | RS485 MODBUS, HART protocols |
Sensor Model | PT100 |
Measure Range | -40℃ - + 120 ℃ |
Work Temperature | -40℃ - + 60 ℃ |
Max Length | 30 meters |
Flange | DN80, PN10, DN50, PN10 or on request |
Material | Stainless Steel |
