4-20ma Temperature Sensor Transmitter With Display

这里可以自定义设置

4-20mA temperature transmitter with display

B站不支持收货地址

B站不支持库存规格

Application:: Liquid or gas, etc.

Measuring Range：: Conventional -50~300°C can be customised -200~500°C

Protection Grade：: IP65

Accuracy：: 0.25%FS、0.5%FS

Process Pressure：: 0-15MPa

Process Temperature：: Conventional -50~300°C can be customised -200~500°C

Process Connection：: External thread. Chuck. Inline

Explosion proof certification:: Intrinsically safe ExiaCT6 Ga (4~20mA output only)

Outer Covering：: stainless steels

Power supply: 12~36VDC

Signal output: 4~20mA, RS485, 0~10VDC, 0~5VDC, 1~5VDC, PT100 (Class 1/3B)

MOQ: 1 SET

Payments:: TT, Paypal, Credit card, Western union

Shipping ways:: Express(DHL,Fedex,TNT,EMS,UPS)/Air/Sea

B站不支持优惠卷

Inquire Online
Download

Cancel

B站不支持产品保障

这里可以自定义设置

PRODUCT INTRODUCTION

RTD sensors
As the Pt100 is an RTD sensor, let’s look first at what an RTD 4-20ma temperature sensor is.
The abbreviation RTD comes from “Resistance Temperature Detector.” It is a temperature sensor in which the resistance depends on temperature; when temperature changes, the sensor’s resistance changes. So, by measuring the sensor’s resistance, an RTD sensor can be used to measure temperature.
RTD sensors are most commonly made from platinum, copper, nickel alloys or various metal oxides.
PRT Sensors
Platinum is the most common material for RTD sensors. Platinum has a reliable, repeatable and linear temperature-resistance relationship. RTD sensors made of platinum are called PRT, “Platinum Resistance Thermometer.” The most common platinum PRT sensor used in the process industry is the Pt100 sensor. The number “100” in the name indicates that is has a resistance of 100 ohms in 0°C (32°F) temperature. More details on that later.

Features

Our digital temperature sensors provide the high accuracy, low power consumption and ease-of-use required for any temperature sensing application, while taking up the smallest packaging footprint. Offering a variety of interface options, our digital temperature sensors integrate seamlessly into your design.

product-4-20mA temperature transmitter with display-Kaidi Sensors-img-2

WIRING DIAGRAM & DRAWING

A temperature transmitter is an electronic device that sends a temperature measurement over two wires to the processing unit. It converts the small electrical signal from the temperature sensor into a more readable signal for the processing unit.

4 20ma temperature transmitter are an essential part of the industry. They convert input signals from sensors such as resistance thermometers, thermocouples, and potentiometers into a consistent analogue or digital output signal. These sophisticated

devices have the capability to provide two-way communication, assisting in device diagnostics, sensor configuration and measurement range customization, as well as error signaling and identification of measuring points.

A temperature transmitter interfaces a temperature sensor with a display or control device. By translating a non-linear millivolt signal from the sensor into a linear milliamp signal that can be sent longer distances without degrading, they are able to

make more accurate measurements as well as providing a platform for digital communication.

Temperature transmitters for all industrial applications
A temperature transmitter with display converts a temperature sensor or thermocouple signal into a stable and standardized output signal. Digital transmitters offer more than just precision measurement: they are intelligent, flexible, and offer high measurement

accuracy. Your process can be safer and more efficient when they are part of the measurement chain.
